Product Details
Place of Origin: Jiangsu
Brand Name: YUSH
Certification: CE, RUV Rheinland (China), GMC(GlobalMarket),ISO9001-2000
Model Number: YSV-7A
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: USD18000
Packaging Details: Wooden case
Delivery Time: 3-5days
Payment Terms: L/C, D/P, T/T, Western Union,Paypal
Supply Ability: 100set
Laser Head: |
SP (USA) |
Laser Type: |
UV |
Laser Wavelength: |
355nm Light Wave UV Laser |
Max Power: |
10W /15w/17W |
Repetition Frequency: |
1-250kHz |
Worktable Location Precision: |
±0.003mm |
Worktable Repetition Precision: |
±0.002mm |
Table Reachition Range: |
500mm*500mm |
CCD Location Precision: |
0.005mm |
Max Working Range: |
460mm*460mm (Larger Area 620*620mm Can Be Customized) |
Beam Spot Size: |
0.015mm ± 0.003mm |
Laser Head: |
SP (USA) |
Laser Type: |
UV |
Laser Wavelength: |
355nm Light Wave UV Laser |
Max Power: |
10W /15w/17W |
Repetition Frequency: |
1-250kHz |
Worktable Location Precision: |
±0.003mm |
Worktable Repetition Precision: |
±0.002mm |
Table Reachition Range: |
500mm*500mm |
CCD Location Precision: |
0.005mm |
Max Working Range: |
460mm*460mm (Larger Area 620*620mm Can Be Customized) |
Beam Spot Size: |
0.015mm ± 0.003mm |
Can be integrated with the production line: gantry structure and flight optical design, easy acc ess to the production line, according to production requirements equipped with dedicated loa ding and unloading and INLINE system to achieve full automation of production, a substantial i ncrease in production efficiency, is designed for FPC and PCB processing Tailored equipment.
PCB UV laser cutting machine application:
Used in cutting a variety of flexible circuit board materials and cover film, clean and free carbonization;cutting rigid material With high quality, high speed, the thickness of up to 1mm (0.04 ").
• Because the UV light is through decomposition and vaporization rather than melting , almost no burrs left after processing.
• Thermal effect is small, no stratification but after cutting, the cutting
edge is precise and smooth, and the sidewall is steep. Can cut a variety of substrate materials, such as silicon, ceramics, glass, etc ;
• Various functional film of precision etching forming.
• Efficient, fast FPC / PCB cutting, drilling and covering the window,
fingerprint identification chip cutting, TF memory card sub-board, mobile phone camera module cutting applications.
| |||||||||||||||||||||||||||||||
| |||||||||||||||||||||||||||||||
No contact will not produce any mechanical stress and deformation.
Linear motor platform speed, high precision, low wear and tear, easy maintenance, low maintenance costs.
Machine Feature:
Efficient, fast FPC / PCB cutting, drilling and covering the window, fingerprint identification chip cutting, TF memory card sub-board, mobile phone camera module cutting applications.
Block, delimit, specify block or select area cut and form directly, cut edge neat rounded, smooth without burr, no overflow glue. Products can be
arranged in a matrix for multiple automatic positioning cutting, especially for fine, difficult, complex patterns such as the appearance of cutting .High- precision CCD automatic positioning, focusing, so that positioning fast and accurate, time-saving, high efficiency, fast delivery.
High-performance laser: the use of international brands of solid-state UV lasers, with a good beam quality, focusing spot is small, uniform power distribution, thermal effect is small, slit width is small, high cutting quality is the perfect cutting quality assurance.
Fast and high precision: High precision, low drift galvanometer with fast coreless linear motor system platform combination, fast cutting while maintaining the high accuracy of the order of microns.
Fully automatic positioning: the use of high-precision CCD automatic positioning, high precision, without human intervention, simple operation, to achieve the same type of one-click mode, greatly improving production efficiency.
Exhaust gas treatment system: suction system can cut all the exhaust gas to eliminate, to avoid the harm to the operator and the pollution of the environment.
High degree of automation: galvanometer automatic correction, automatic focus, full automation, the use of laser displacement sensor automatically adjust the focus to the height of the table to achieve fast alignment, time-saving peace of mind.
Easy to learn software: independent research and development based on the Windows system control software, easy to operate the Chinese interface, friendly and beautiful, powerful and diverse, easy to operate.
laser source
Using the United States imported UV shock Light, excellent optical performance, long life, simple structure, easy to operate. Thisbrand has been use for over 10years
.
CCD
High speed image acquisition system and High-precision image positioning and matching system which ensures the High precision
